Sawmills are the industrial powerhouse where timber transformation takes place. These facilities house an array of specialised machinery designed to efficiently convert rough logs into usable lumber. While the basic concept seems straightforward – cutting a log into pieces – the reality involves a multi-stage process that balances maximising yield with producing high-quality final products. This article will unveil the intricacies of sawmill production, highlighting the key equipment used at each stage to unlock the potential within each log.

Stage 1: Log Intake and Debarking

The first step involves receiving logs at the mill. Large grapple loaders or log decks equipped with chains or rollers manoeuvre logs into position. Next, the debarker removes the bark, a crucial step as it prevents contamination in downstream processes and improves lumber quality. There are two main debarking technologies:

Debarking Technology




Ring Debarker

A rotating ring with knives shaves off the bark

Fast, efficient for large-diameter logs

May damage delicate wood

Drum Debarker

Logs tumble inside a rotating drum with abrasive inserts, removing bark

Gentler on wood, suitable for smaller diameters

Slower than ring debarkers

Stage 2: Log Bucking and Log Carriage

Once debarked, the logs are precisely cut to length using a bucksaw. Modern mills often employ automated bucksaws integrated with a log carriage system. The carriage clamps onto the log and feeds it through the primary breakdown process.

Stage 3: Primary Breakdown

Here, the log is transformed into large canted pieces using a handsaw. Bandsaws are popular for this stage due to their thin kerf (the width of material removed during cutting), minimising waste. The resulting canted pieces then move on to the secondary breakdown stage.

Stage 4: Secondary Breakdown

The secondary breakdown stage further reduces the cants into boards of various thicknesses. Several equipment options exist, each with its strengths and weaknesses:

Secondary Breakdown Equipment





A vertical bandsaw that cuts cants into thinner boards

Precise cuts, good for high-value lumber

Lower production capacity compared to other options


Multiple circular saws working together to simultaneously cut cants into boards

High production capacity, suitable for commodity lumber

Less precise cuts than resaws


Trims the wane (curved outer edge) from canted pieces to produce squared boards

Improves lumber yield and value

Limited to trimming and not full breakdown

Stage 5: Trimming and Sorting

After secondary breakdown, trimmers remove any imperfections or end defects from the boards. Finally, automated sorting systems segregate the finished lumber based on species, size, and grade.

A Deep Dive into the Sawmill Production Process and the Equipment that Makes it Possible - Image 1

Stage 6: Stacking and Packaging

The sorted lumber is then stacked and packaged for transport or further processing at planing mills that smooth the surface of the boards.

A Deep Dive into the Sawmill Production Process and the Equipment that Makes it Possible - Image 2
